MC Rondo Red Cartridge

$499.00

The all-around cartridge

Category:

Description

Ortofon MC Rondo Red is a very homogeneous all round cartridge

The Rondo Red has a very fine polished elliptical diamond is mounted on a cylindrical aluminum cantilever.

The cartridge is clearly out of the same family of sound as Bronze and Blue – all of them taking benefit from the wooden housings.

Recommended load around 100 Ohm or even higher if added “air“ might be preferred.

The MC Rondo Red sound image will tend to less dynamic strength and smoother reproduction-working perfect with all sorts of not very complex music.

Technical Specs

Technical Specs

Stylus tip radius – r/R 8/18 µm

Output voltage at 1000 Hz, 5cm/sec. 0,5 mV
Channel balance at 1 kHz – 2 dB
Channel separation at 1 kHz – 22 dB
Channel separation at 15 kHz – 15 dB
Frequency range at – 3dB – 20-30.000 Hz
Frequency response – 20-20.000 Hz ±2 dB
Tracking ability at 315Hz at recommended tracking force – 80 µm
Compliance, dynamic, lateral – 15 µm/mN
Stylus type – Nude Elliptical on Aluminium cantilever
Tracking force range – 2-2,5 g (20-25 mN)
Tracking force, recommended – 2,3 g (23 mN)
Tracking angle – 20°
Internal impedance, DC resistance – 6 Ohm
Recommended load impedance – 10-200 Ohm
Cartridge body material – Grinded wood/Resin comp.
Cartridge colour – Red
Cartridge weight – 10,5 g
